Model |
e-STUDIO
2515AC |
e-STUDIO
3015AC |
e-STUDIO
3515AC |
e-STUDIO
4515AC |
e-STUDIO
5015AC |
General Feature |
Copy / Print Speed (ppm) |
Color |
25 |
30 |
35 |
45 |
50 |
B & W |
25 |
30 |
35 |
45 |
50 |
Warm-up Time |
Approx. 20 sec. |
Memory |
4 GB |
Storage |
320GB Self-Encryption HDD |
Dimension (W × D × H) |
585 × 641* × 787 mm / 23" × 25.2"* × 31"* |
Weight |
Less than 78.1 kg / 172.2 lb |
Input Paper Capacity |
Standard |
1,200 sheets |
Maximum |
3,200 sheets |
Available Paper Weight |
52 - 280 g/m² / 14 lb. Bond - 100 lb. Cover |
Available Paper size |
100 × 148 to 320 x 460mm / 100 × 148 to 12.6" x 18.1", Banner paper (1,200 mm) |
Document feeder |
Optional 300-sheet DSDF or 100-sheet RADF |
Finishing Option |
Multi-Position stapling finisher, Saddle Stitching Finisher, Inner Finisher, Job Separator |
Copier Feature |
First Copy Speed |
Color |
Less than 7.8 sec. |
Less than 5.7 sec. |
B & W |
Less than 5.9 sec. |
Less than 4.4 sec. |
Resolution |
600 × 600 dpi |
Multiple Copy |
Up to 999 |
Printer Feature |
Resolution |
600dpi x 600dpi 5bit*1 2400dpi (Equivalence) x 600dpi (with smoothing)*2
*1 or *2 is selected by copy mode automatically. No selectable by user. |
PDL |
PCL6 Emulation, PS3 Emulation, XPS |
Interface |
Standard |
USB (High speed), 10/100/1000BASE-T |
Option |
Wireless LAN (IEEE802.11 b/g/n), Bluetooth |
Scanner Feature |
Resolution |
100/150/200/300/400/600dpi |
Scan Speed |
DSDF |
Up to 240 spm (Duplex) / Up to 120 spm (Simplex) (300 dpi) |
RADF |
Up to 73 spm (300 dpi) |
Data format |
Standard |
TIFF, PDF, XPS, JPEG, Slim PDF, PDF/A |
Option |
DOCX, EXLS, PPTX, Searchable PDF |
Scan Protocol |
SMB, FTP, IPX/SPX, FTPS, USB, Netware |
Scan features |
File, Email, USB, e-Filing Box, TWAIN, Local HDD, Share Point, iFax, Fax, WS Scan |
Internet Fax |
ITU-T T.37 (Simple mode) |
Fax Feature (option) |
Communication mode / Modem Speed |
Super G3 / 33.6kbps - 2.4 kbps |
Data Compression |
JBIG, MMR, MR, MH |
Number of Lines (Std. / Max.) |
1 / 2 |
Phonebook |
3,000 stations |
Security Feature |
Standard |
Self-Encryption HDD, Private Print, Encrypted PDF, User Authentication, Role Based Access Control, IP/MAC address filtering, SNMPv3, SSL |
Optional |
Data Overwrite, IPsec, Hardcopy Security Printing, FIPS certified Self-Encryption HDD |
|
* Depth is different depending on angle of the control panel.
**Specifications, and availability of models and options vary by region. |
|
